    10CRF6430 - 10” coaxial with planar ribbon HF

    $425.00

    • planar ribbon HF with Kapton diaphragm
    • very balanced response extended both in LF and HF range up to 30kHz
    • precise 100° conical coverage with even pattern control down to 1000Hz
    • ideal for cinema surround systems with immersive digital audio formats
    • 500 W continuous program power LF
    • dual aluminum demodulation rings for low LF/MF distortion
    • completely independent LF and HF magnetic systems eliminate flux modulation and related intermodulation distortion in HF range
    • optional premium XO

    Click icon below to start download
